Loctek

Loctek D7 Monitor Arm

$ 289.00 USD

Sale Sold out

Model D7A D7L-Heavy Monitor D7H-Super Heavy monitor D7D-Dual Monitor

Quantity

Loctek D7 Heavy Duty Desk Mount Monitor Arm W/ USB

The Loctek D7 Desk Mount Monitor Arm is easily adjusted, allowing you to effortlessly work in a more ergonomic and healthy posture, and avoid neck and back pain associated with "Desk hunch." This high performance monitor mount offers a wide range of features, including ports for audio, mic and USB devices.

This Sit-to-Stand desk comes in many variants:

Single Monitor comes in a heavy and super heavy version
Dual Monitor
Triple Monitor

Loctek D7 Features

Constructed with aircraft-grade aluminum - Which offers a stylish anti-scratch surface.
Adjust your workstation to a more ergonomically correct position with minimal effort
Gas Spring Hovering System - Gracefully adjusts monitor height
360° Horizontal Arm Rotation - (180° in each direction)
Front-Loading Ports - For audio, mic & USB 3.0
Fits most monitors
Easily Organize Your Desk - With a cable management system
Extend or Retract Monitor Arm - rotate monitor to landscape or portrait mode
10-Year limited manufacturer warranty

Loctek D7A Monitor Arm Max Height Max Extension

Loctek D7A Specifications

Manufacturer	Loctek
Model Number	D7A
Additional Functions	Audio, Mic & USB Ports
Screen Size Range	10~27"
Supported VESA	75 x 75, 100 x 100 mm
Swivel	±90°
Rotation	±180°
Height Range	Max Height 19.7" Max Extension 21.6"
Loading Capacity	4.4~19.8 lbs
Weight	9.03 lbs
Desk Thickness	0.79”-4.72” (Clamp) 0.79”-4.72” (Grommet)

Loctek D7A Review

Loctek D7A Dimensions

Download the D7A Dimensional Illustration

Loctek D7A Installation

Setting up your D7A is easy (no tools required), but for more detailed information, please reference the Loctek D7A Installation Manual

Loctek D7L Specifications

Manufacturer	Loctek
Model Number	D7L
Additional Functions	Audio, Mic & USB Ports
Screen Size Range	10"~34"
Supported VESA	75 x 75, 100 x 100 mm
Swivel	±90°
Rotation	±180°
Height Range	Max Height 19.7" Max Extension 21.6"
Loading Capacity	13.2~33 lbs
Weight	13.9 lbs
Desk Thickness	0.98”-4.72” (Clamp) 1/3 inch- 2.75 inch (Grommet)

Loctek D7A Monitor Arm Gas Spring

Loctek D7L Installation

Setting up your D7L is easy (no tools required), but for more detailed information, please reference the Loctek D7L Installation Manual

Loctek D7H Specifications

Manufacturer	Loctek
Model Number	D7H
Additional Functions	Audio, Mic & USB Ports
Screen Size Range	10~34"
Supported VESA	75 x 75, 100 x 100 mm
Swivel	±90°
Rotation	±180°
Height Range	Max Height 19.7" Max Extension 21.6"
Loading Capacity	4.4~19.8 lbs
Color	Silver
Desk Thickness	0.98"-4.72" (Clamp) 1/3 inch-2.75 inch (Grommet)

Loctek D7A Monitor Arm Cable Management

Loctek D7H Installation

Setting up your D7H is easy (no tools required), but for more detailed information, please reference the Loctek D7H Installation Manual

Loctek D7D Specifications

Manufacturer	Loctek
Model Number	D7D
Additional Functions	Audio, Mic & USB Ports
Screen Size Range	10~27"
Supported VESA	75 x 75, 100 x 100 mm
Swivel	±90°
Rotation	±180°
Height Range	Max Height 18.8" Max Extension 20.5"
Loading Capacity	4.4~19.8 lbs
Weight	15.15 lbs
Desk Thickness	0.79”-4.72” (Clamp) 0.98”-4.72” (Grommet)

Loctek D7D Dual Monitor Adjustable Arm

Loctek D7D Dimensions

Download the D7D Dimensional Illustration

Loctek D7D Installation

Setting up your D7D is easy (no tools required), but for more detailed information, please reference the Loctek D7D Installation Manual

Loctek D7T Specifications

Manufacturer	Loctek
Model Number	D7T
Additional Functions	Audio, Mic & USB Ports
Screen Size Range	10~24"
Supported VESA	75 x 75, 100 x 100 mm
Swivel	±90°
Rotation	±180°
Tilt Angle	-90°~15°
Loading Capacity	4.4~19.8 lbs For Each
Weight	16.96 lbs
Dimensions	25.1 x 5.9 x 11.3 inches
